Wizard
Administrator
Wizard
  • Threads: 1520
  • Posts: 27125
Joined: Oct 14, 2009
November 28th, 2024 at 2:25:03 PM permalink
Happy Thanksgiving my fellow math nerds! Here is an easy geometry puzzle to help celebrate.

ACED is a square of side length 2. AB = BC. What is the area of the blue region?



I label some extra points for purposes of discussion.
"For with much wisdom comes much sorrow." -- Ecclesiastes 1:18 (NIV)
charliepatrick
charliepatrick
  • Threads: 39
  • Posts: 3017
Joined: Jun 17, 2011
November 28th, 2024 at 5:22:52 PM permalink
I've constructed a few more lines.
By similar triangles JKB has sides in the ratio of 2 to 1 (ref BCE), and JKH has equal sides (ref CBH), thus one can say that JK=KH=x and KB=2x. But BH=3x=1. So x=1/3.
So area of JKH = 1/3 * 1/3 * 1/2 = 1/18.
Area of LKB is twice this = 2/18.
So total of the four triangles that make up BGHJ = 6/18 = 1/3.

Another way of looking it is consider copying move BGK to the right of BKJ and similarly KGH moves, to form the rectangle. This rectangle has height of 1 (BH) and width = 1/3; hence the area = 1/3.
Wizard
Administrator
Wizard
  • Threads: 1520
  • Posts: 27125
Joined: Oct 14, 2009
November 28th, 2024 at 8:19:52 PM permalink
Quote: charliepatrick

I've constructed a few more lines.
By similar triangles JKB has sides in the ratio of 2 to 1 (ref BCE), and JKH has equal sides (ref CBH), thus one can say that JK=KH=x and KB=2x. But BH=3x=1. So x=1/3.
So area of JKH = 1/3 * 1/3 * 1/2 = 1/18.
Area of LKB is twice this = 2/18.
So total of the four triangles that make up BGHJ = 6/18 = 1/3.

Another way of looking it is consider copying move BGK to the right of BKJ and similarly KGH moves, to form the rectangle. This rectangle has height of 1 (BH) and width = 1/3; hence the area = 1/3.

link to original post



I agree! Here is my solution (PDF).
"For with much wisdom comes much sorrow." -- Ecclesiastes 1:18 (NIV)
Wizard
Administrator
Wizard
  • Threads: 1520
  • Posts: 27125
Joined: Oct 14, 2009
November 29th, 2024 at 4:31:05 AM permalink


Two circles are inscribed in a rectangle of height 81. There is a line segment of length 56 extending to the edge of both circles and goes through where the circles meet and is parallel to the vertical edge of the rectangle.

How wide is the rectangle?
"For with much wisdom comes much sorrow." -- Ecclesiastes 1:18 (NIV)
davethebuilder
davethebuilder
  • Threads: 10
  • Posts: 73
Joined: Jan 11, 2015
November 29th, 2024 at 6:34:23 AM permalink
Conditions: AB=BC=81, EF=56, EF//AD//BC, Line 'EF' passes through the contact point where the two circles meet.

Solution: Join the centre of both circles. Let the centre of the small circle be C1 and the centre of the large circle be C2. Let the radius of the small circle be R1 and the radius of the large circle be R2. Call the intersection point M.

Draw a line from C1 to meet EF at right angles and call this point X. Draw a line from C2 to meet EF at right angles and call this point Y.

By the law of triangles XY = EF/2 = 56/2 = 28.

By deduction: radius of large circle (R2) = (81 - 28 - R1) = 53 - R1

Distance C1-C2 = 53 - R1 + R1 = 53.

Extend line C2-Y to AD and draw a line from C1 parallel with AD to meet DC. Call the intersection point of the two construction lines point Z.

By deduction: C1-Z = 28,

By deduction: C2-Z = Sq, root (53*53 - 28*28) = 45

Answer: CD = R1 + 45 + 53 - R1
= 98
Casino Enemy No.1
Wizard
Administrator
Wizard
  • Threads: 1520
  • Posts: 27125
Joined: Oct 14, 2009
November 30th, 2024 at 6:30:36 AM permalink
Quote: davethebuilder


Answer: CD = R1 + 45 + 53 - R1
= 98
link to original post



I agree.

Dave, can you please put answers in the future in spoiler tags.
"For with much wisdom comes much sorrow." -- Ecclesiastes 1:18 (NIV)
davethebuilder
davethebuilder
  • Threads: 10
  • Posts: 73
Joined: Jan 11, 2015
November 30th, 2024 at 8:01:18 AM permalink
No problem, will do.

By the way, there's a typo in the first line, it should read AD=BC=81.
Casino Enemy No.1
Wizard
Administrator
Wizard
  • Threads: 1520
  • Posts: 27125
Joined: Oct 14, 2009
December 11th, 2024 at 7:26:44 PM permalink


Here is an easy puzzle that came up on my Facebook feed.
"For with much wisdom comes much sorrow." -- Ecclesiastes 1:18 (NIV)
davethebuilder
davethebuilder
  • Threads: 10
  • Posts: 73
Joined: Jan 11, 2015
December 11th, 2024 at 8:59:36 PM permalink
  • Let the height of the table be ‘x’
  • Let the height of the Cat be ‘y’
  • Let the height of the Tortoise be ‘z’
  • By deduction: x = 170 – y + z
  • By deduction: x = 130 + y – z
  • Solving: y = z + 20
  • Substituting: x = 170 – (z + 20) + z
  • Answer: x = 150cm
  • Check: x = 130 + (z + 20) – z
  • Answer: x = 150cm
  • Casino Enemy No.1
    Wizard
    Administrator
    Wizard
    • Threads: 1520
    • Posts: 27125
    Joined: Oct 14, 2009
    December 12th, 2024 at 4:06:39 AM permalink
    Quote: davethebuilder

  • Let the height of the table be ‘x’
  • Let the height of the Cat be ‘y’
  • Let the height of the Tortoise be ‘z’
  • By deduction: x = 170 – y + z
  • By deduction: x = 130 + y – z
  • Solving: y = z + 20
  • Substituting: x = 170 – (z + 20) + z
  • Answer: x = 150cm
  • Check: x = 130 + (z + 20) – z
  • Answer: x = 150cm

  • link to original post



    I agree.
    "For with much wisdom comes much sorrow." -- Ecclesiastes 1:18 (NIV)
    charliepatrick
    charliepatrick
    • Threads: 39
    • Posts: 3017
    Joined: Jun 17, 2011
    December 12th, 2024 at 4:34:36 AM permalink
    The annual GCHQ puzzle appeared yesterday, I don't know the answers but they were in the paper today.

    You can download the PDF here: https://www.gchq.gov.uk/news/gchq-christmas-challenge-2024 or https://www.gchq.gov.uk/files/GCHQ%20Christmas%20Challenge%202024.pdf

    Edit added SPOILER : I've found, but not read, the answers can be found here : https://www.pressreader.com/uk/daily-mail/20241212/282093462326112
    Wizard
    Administrator
    Wizard
    • Threads: 1520
    • Posts: 27125
    Joined: Oct 14, 2009
    December 12th, 2024 at 2:10:04 PM permalink
    Sorry to step on the puzzle above. For those more inclined to geometry, here is one for you.



    The yellow circle has a radius of 1. What is the area of the red circle?
    "For with much wisdom comes much sorrow." -- Ecclesiastes 1:18 (NIV)
    ThatDonGuy
    ThatDonGuy
    • Threads: 123
    • Posts: 6745
    Joined: Jun 22, 2011
    December 12th, 2024 at 3:53:20 PM permalink

    Let C be the height of the cat, T the height of the turtle, and X the height of the table, which is the desired value
    Top image: C + X - T = 170
    Bottom image: T + X - C = 130
    Add them up: (C - C) + 2X + (T - T) = 300
    2X = 300, so X = the height of the table = 150 cm

    ThatDonGuy
    ThatDonGuy
    • Threads: 123
    • Posts: 6745
    Joined: Jun 22, 2011
    December 12th, 2024 at 4:14:19 PM permalink
    Quote: charliepatrick

    The annual GCHQ puzzle appeared yesterday, I don't know the answers but they were in the paper today.

    link to original post


    I got into a bit of a discussion about this over on the Straight Dope Message Board:

    Santa's trail says, "We Wish You a Merry Christmas" twice, in Morse code - but since it's British (especially as puzzle 2 expects you to know what a Blue Peter Badge and Blackpool Tower are), shouldn't it be, "Happy Christmas"?

    ThatDonGuy
    ThatDonGuy
    • Threads: 123
    • Posts: 6745
    Joined: Jun 22, 2011
    December 12th, 2024 at 6:02:45 PM permalink
    Quote: Wizard

    The yellow circle has a radius of 1. What is the area of the red circle?
    link to original post



    Let Y be the center of the yellow circle, R the center of the red circle, B the center of the blue semicircle, and P and Q the points of tangency of the yellow circle to the top and right edges of the bounding square.
    Let x be the radius of the red circle, and y the radius of the yellow semicircle.

    Since the distance from the center of the circle to Q is 1, the distance from P to the upper right corner of the square is also 1, so the distance from P to B is 1 - y.
    Also, since the yellow and blue circles are tangent, YB = the sum of their radii = 1 + y.
    Pythagorean Theorem: 1^2 + (1 - y)^2 = (1 + y)^2
    y = 1/4
    Draw a line through R that is perpendicular to the top side (and parallel to the right side) of the square.
    Let C be the point where this line intersects the top of the square.
    Since the line segment from R to the right edge of the square is a radius of R, its distance is x, which means the distance from C to the upper right corner of the square is also x, and CB has length y - x. Also, since the blue semicircle and red circle are tangent, RB = y + x.
    Pythagorean Theorem: (y - x)^2 + z^2 = (y + x)^2, or z^2 = (y + x)^2 - (y - x)^2 = 4xy = x (since y = 1/4).
    CR = sqrt(x)
    Let D be the point where YQ intersects the line through R parallel to the right edge; RD = 1 - sqrt(x), and YD = 1 - x
    Since the yellow and red circles are tangent, YR = 1 + x
    Pythagorean Theorem: (1 - sqrt(x))^2 + (1 - x)^2 = (1 + x)^2 = 4x
    Take the square root of both sides: 1 - sqrt(x) = 2 sqrt(x), or 1 = 3 sqrt(x)
    sqrt(x) = 1/3, so the radius of the red circle = (1/3)^2 = 1/9.

    ChesterDog
    ChesterDog
    • Threads: 9
    • Posts: 1732
    Joined: Jul 26, 2010
    December 12th, 2024 at 7:24:33 PM permalink


    Wizard
    Administrator
    Wizard
    • Threads: 1520
    • Posts: 27125
    Joined: Oct 14, 2009
    Thanked by
    ChesterDog
    December 13th, 2024 at 4:08:35 AM permalink
    Don & CD -- I agree!
    "For with much wisdom comes much sorrow." -- Ecclesiastes 1:18 (NIV)
    ThatDonGuy
    ThatDonGuy
    • Threads: 123
    • Posts: 6745
    Joined: Jun 22, 2011
    Thanked by
    ChesterDog
    December 13th, 2024 at 6:59:05 AM permalink
    Quote: Wizard

    Don & CD -- I agree!
    link to original post


    But ChesterDog gets the beer this time because you did ask for the area, and my answer was the radius.
    charliepatrick
    charliepatrick
    • Threads: 39
    • Posts: 3017
    Joined: Jun 17, 2011
    December 13th, 2024 at 7:17:56 AM permalink
    ^ When it comes to beer, it's the volume that really counts. Luckily we still have pints here!
    Wizard
    Administrator
    Wizard
    • Threads: 1520
    • Posts: 27125
    Joined: Oct 14, 2009
    December 15th, 2024 at 5:14:25 PM permalink
    Here is another one that came through my Facebook feed:

    x^2 - y^2 = 64
    xy = 8
    Find x+y.
    "For with much wisdom comes much sorrow." -- Ecclesiastes 1:18 (NIV)
    ThatDonGuy
    ThatDonGuy
    • Threads: 123
    • Posts: 6745
    Joined: Jun 22, 2011
    December 15th, 2024 at 7:05:29 PM permalink
    Quote: Wizard

    Here is another one that came through my Facebook feed:

    x^2 - y^2 = 64
    xy = 8
    Find x+y.
    link to original post



    x^2 - (8/x)^2 = 64
    x^2 - 64 / x^2 = 64
    (x^2)^2 - 64 = 64 x^2
    (x^2)^2 - 64 x^2 - 64 = 0
    (x^2)^2 - 64 x^2 + 32^2 = 32 * 34 = 64 * 17
    (x^2 - 32)^2 = (8 sqrt(17))^2
    x^2 = 32 +/- 8 sqrt(17)
    y^2 = x^2 - 64 = +/- 8 sqrt(17) - 32
    x^2 + y^2 = 16 sqrt(17)
    (x + y)^2 = x^2 + 2xy + y^2 = x^2 + y^2 + 16 = 16 + 16 sqrt(17)
    x + y = +/- 4 sqrt(1 + sqrt(17))
    I know the positive is correct; not sure about the negative

    Wizard
    Administrator
    Wizard
    • Threads: 1520
    • Posts: 27125
    Joined: Oct 14, 2009
    December 15th, 2024 at 8:51:40 PM permalink
    Quote: ThatDonGuy


    x^2 - (8/x)^2 = 64
    x^2 - 64 / x^2 = 64
    (x^2)^2 - 64 = 64 x^2
    (x^2)^2 - 64 x^2 - 64 = 0
    (x^2)^2 - 64 x^2 + 32^2 = 32 * 34 = 64 * 17
    (x^2 - 32)^2 = (8 sqrt(17))^2
    x^2 = 32 +/- 8 sqrt(17)
    y^2 = x^2 - 64 = +/- 8 sqrt(17) - 32
    x^2 + y^2 = 16 sqrt(17)
    (x + y)^2 = x^2 + 2xy + y^2 = x^2 + y^2 + 16 = 16 + 16 sqrt(17)
    x + y = +/- 4 sqrt(1 + sqrt(17))
    I know the positive is correct; not sure about the negative


    link to original post



    That's not what I got, but maybe I'm in the one in error. Hopefully we get a third opinion.
    "For with much wisdom comes much sorrow." -- Ecclesiastes 1:18 (NIV)
    charliepatrick
    charliepatrick
    • Threads: 39
    • Posts: 3017
    Joined: Jun 17, 2011
    December 16th, 2024 at 3:35:51 AM permalink
    ^ If x and y are solutions then so would be -x and -y. The square of -x = the square of x, and xy = (-x)(-y). I think I saw this puzzle on facebook.
    davethebuilder
    davethebuilder
    • Threads: 10
    • Posts: 73
    Joined: Jan 11, 2015
    December 16th, 2024 at 7:30:54 AM permalink

    x² - y² = 64
    xy = 8
    Find x + y

    Solution:
    If xy = 8, y = 8/x
    x² - (8/x)² = 64
    x² - (64/x²) = 64
    (x²)² - 64x² - 64 = 0
    Convert quartic equation into quadratic form by letting a = x²
    a² - 64a - 64 = 0
    a = [Sq. root 64 + (Sq. root (64*68))]/2
    x = Sq. root {[Sq. root 64 + (Sq. root (64*68))]/2}
    x = 8.061317
    Substituting: y = 8/x
    y = 8/8.061317
    = 0.992393
    Solution: x + y = 8.061317 + 0.992393
    = 9.05371
    Casino Enemy No.1
    Wizard
    Administrator
    Wizard
    • Threads: 1520
    • Posts: 27125
    Joined: Oct 14, 2009
    December 16th, 2024 at 8:24:19 AM permalink
    I concede that Dave and Don agree and calculations in Excel confirms it. I think nobody will mind if I move this out of Spoiler tags.

    Using trial and error these values of x and y come close:

    x = 8.061315
    y = 0.992370661
    xy = 7.999812497
    x+y = 9.053685661

    I was trying to argue why my answer was also right, but in putting it in writing for this post, I caught my error.
    "For with much wisdom comes much sorrow." -- Ecclesiastes 1:18 (NIV)
    Wizard
    Administrator
    Wizard
    • Threads: 1520
    • Posts: 27125
    Joined: Oct 14, 2009
    December 24th, 2024 at 8:44:10 AM permalink
    You roll an icosahedron (20-sided die) until it lands on the same side it already landed on at any point.

    1. What is the expected number of rolls, including the ending roll?
    2. Is there a formula for the expected rolls for an n-sided die?
    Last edited by: Wizard on Dec 24, 2024
    "For with much wisdom comes much sorrow." -- Ecclesiastes 1:18 (NIV)
    ThatDonGuy
    ThatDonGuy
    • Threads: 123
    • Posts: 6745
    Joined: Jun 22, 2011
    December 24th, 2024 at 9:13:19 AM permalink
    Quote: Wizard

    You roll an icosahedron (20-sided die) until it lands on the same side it already landed on.

    1. What is the expected number of rolls?
    2. Is there a formula for the expected rolls for an n-sided die?
    link to original post


    Clarification needed: does it have to be the same side as the previous roll, or do you roll until any number comes up twice (e.g. if you roll 1, 2, 4, 12, 2, you stop at the second 2)?
    Wizard
    Administrator
    Wizard
    • Threads: 1520
    • Posts: 27125
    Joined: Oct 14, 2009
    December 24th, 2024 at 11:37:18 AM permalink
    Quote: ThatDonGuy

    Clarification needed: does it have to be the same side as the previous roll, or do you roll until any number comes up twice (e.g. if you roll 1, 2, 4, 12, 2, you stop at the second 2)?
    link to original post



    You roll until any number comes up twice. They do not need to occur on consecutive rolls. Be sure to count the final (duplicate) roll. In your example, there were 5 rolls.

    p.s. I amended the original wording to be more clear.
    Last edited by: Wizard on Dec 24, 2024
    "For with much wisdom comes much sorrow." -- Ecclesiastes 1:18 (NIV)
    ThatDonGuy
    ThatDonGuy
    • Threads: 123
    • Posts: 6745
    Joined: Jun 22, 2011
    December 25th, 2024 at 11:51:41 AM permalink
    Quote: Wizard

    You roll an icosahedron (20-sided die) until it lands on the same side it already landed on at any point.

    1. What is the expected number of rolls, including the ending roll?
    2. Is there a formula for the expected rolls for an n-sided die?
    link to original post



    For N-sided dice from 2 to 20, I get these fractions:
    2: 5 / 2
    3: 26 / 9
    4: 103 / 32
    5: 2,194 / 625
    6: 1,223 / 324
    7: 472,730 / 117,649
    8: 556,403 / 131,072
    9: 21,323,986 / 4,782,969
    10: 7,281,587 / 1,562,500
    11: 125,858,034,202 / 25,937,424,601
    12: 180,451,625 / 35,831,808
    13: 121,437,725,363,954 / 23,298,085,122,481
    14: 595,953,719,897 / 110,730,297,608
    15: 26,649,932,810,926 / 4,805,419,921,875
    16: 3,211,211,914,492,699 / 562,949,953,421,312
    17: 285,050,975,993,898,158,530 / 48,661,191,875,666,868,481
    18: 549,689,343,118,061 / 91,507,169,819,844
    19: 640,611,888,918,574,971,191,834 / 104,127,350,297,911,241,532,841
    20: 4,027,894,135,040,576,041 / 640,000,000,000,000,000

    I am trying to find a formula, but so far it has eluded me

    • Jump to:
